A-25
- IV Series User's Manual (Monitor) -
A
Error Messages
Message Cause Remedy
Output/
Indicator
Some tools can not correctly judge
because of insufcient outline
extraction amount as a result of
“Ext. Master Save”.
(Matching rate is 0.)
Check tool conguration.
An external master image
registration error (with
registered master image)
occurred. The following
errors occurred even
though the image was
updated and registered
as a master image.
For the new master
image, the outline
cannot be extracted
with the outline tool.
For the new master
image, the area cannot
be extracted with the
Color Area/Area tool.
The brightness
correction cannot be
performed correctly for
the new master image.
An external master image
registration error can be xed
using one of the following
procedures.
Successful next external
master image registration
Clearing the Error input
Switching the program
number
Proceeding to the settings
screen of the sensor
Checking that the image to be
registered and the detection
tools/position adjustment
settings are applicable.
Adjusting the brightness of the
image to be registered properly.
*2
Some tools can not correctly
judged because area is 0 as a
result of “Ext. Master Save”.
(Matching rate is 0.)
Check tool conguration.
Brightness of brightness adjustment
area is not adjustable as a result of
“Ext. Master Save”.
Check conguration of brightness
adjustment.
Outer master registration fails
because image is not captured.
An external master image
registration error (with no
registered master image)
occurred. The master
image is not updated.
The image to be
registered as a master
image was not imaged.
The work memory is
insufcient.
An external master image
registration error can be xed
using one of the following
procedures.
Successful in next external
master image registration
Clearing the Error input
Switching the program
number
Proceeding to the settings
screen of the sensor
Taking an image to be
registered as a mater image
and registering it as an external
master image.
Deleting one or more detection
tools.
*2
Outer master registration fails
because of lack of work memory.
Monitor fatal error (XXX) occurred.
Contact your nearest KEYENCE
ofce.
A system error occurred
in the monitor.
It is conceivable that a
fault occurred inside the
monitor.
Turn on the monitor power again.
If the same error occurs,
contact your nearest KEYENCE
ofce.
*3
Monitor system error happens.
Turn on monitor.
If not turned on, contact local
service center.
