Settings List
4. Output Assignment
Menu Description Setting range
Reference
page
OUT1 to OUT4
Sets the output items
to be assigned to the
output line.
Total Status
Tot. StatusNG
RUN
BUSY
Error
Pos. Adj.
Judge result of each
tool (Tool 1 to Tool 16)
Logical operation result
of each tool
(Logic 1 to Logic 4)
OFF (not used)
4-60
Trigger Error
Selects whether to
ON/OFF the output
when the trigger error
occurred.
ON
OFF (default value)
4-60
Extended
functions
menu
Logic Settings
(Logic 1 to 4)
Logic
Selects the logical
operation method of
logics.
AND
OR
4-63
(Tool selection)
Select tools to be
assigned to the logic.
Unused
Used
Used (Inverse)
4-63
Total Status Conditions
Selects a condition for
the total status result.
All Tools OK
Any Tools OK
Logic 1 to 4
4-65
