A-17
- IV Series User's Manual (Monitor) -
A
Settings List
Menu Description Setting range
Reference
page
Pos.
Adj.
Edit
Window
Window
Shape
Select a window shape
to specify an area of the
target to be detected.
Rect (default value)
Circle
4-53
Search
Region
Species an area to
search an outline of the
target.
Entire
Partial
4-55
Fine Tune
Outline
Remove
Outline
Disables an unnecessary
outline which interrupts
the stabilized detection,
and then judges.
Undo
Clear
4-55
Eraser
Width
Selects the eraser width of
the pen when specifying
an unnecessary outline.
Narrow (default value)
Middle
Wide
4-55
Sensitivity
Select an extraction
sensitivity of an outline.
High
Normal (default value)
Low
4-55
Limit Adjustment
Adjusts a threshold used
in anomaly detection.
0 to 100 (default value: 70) 4-53
Extended
functions
menu
Rotation
Range
Sets an angle limit for
adjusting position to the
rotating direction.
0 to ±180°
(default value: ± 20°)
4-57
Margin
Select whether or not to
allow the margin for the
limited angle.
ON (default value)
OFF
4-57
Edit Tool
Edits the settings of the
tool which has already
been set.
- 4-31
Delete Tool
Deletes an unnecessary
tool.
- 4-31
Extended
functions
menu
Copy Tool
Copies the tool which has
been set and pastes it to
the same position.
This is for the Outline tool
and the Color Area/Area
tool.
- 4-58
