A-15
- IV Series User's Manual (Monitor) -
A
Settings List
2. Master Registration
Menu Description Setting range
Reference
page
Register Live Image as Master
Registers the image
imaged by sensor as a
master image.
- 4-21
Extended
functions
menu
Select Img From Image
History
Registers the image of
the image history in the
memory of the sensor as
a master image.
- 4-22
Select Img From USB
Memory
Registers the image in USB
memory as a master image.
- 4-24
Brightness Correction
Sets a reference of
brightness to the master
image.
- 4-26
3. Tool Settings
Menu Description Setting range
Reference
page
Add Tool
Newly sets a tool.
- 4-31
Outline
Edit
Window
Window
Shape
Select a window shape
to specify an area of the
target to be detected.
Rect (default value)
Circle
4-33
Search
Region
Species an area to
search an outline of the
target.
Entire (Without position
adjustment)
Partial (With position
adjustment)
4-35
Fine Tune
Outline
Remove
Outline
Disables an unnecessary
outline which interrupts
the stabilized detection,
and then judges.
Undo
Clear
4-35
Eraser
Width
Selects the eraser width of
the pen when specifying
an unnecessary outline.
Narrow (default value)
Middle
Wide
4-35
Sensitivity
Select an extraction
sensitivity of an outline.
High
Normal (default value)
Low
4-36
Limit Adjustment
Adjusts a threshold used
in anomaly detection.
0 to 100
(default value: 70)
4-33
Extended
functions
menu
Rotation
Range
Sets an angle limit for
detecting outlines to the
rotating direction.
0 to ±180°
(default value: ± 20°)
4-38
Margin
Select whether or not to
allow the margin for the
limited angle.
ON (default value)
OFF
4-38
Search
Algorithm
Select a detection mode
for outline search.
High Accuracy
High Speed (default value)
4-38
Tool Name
Sets an arbitrary name to
the tool.
Up to 8 characters
(English and Japanese
single byte characters)
4-39
