A-14
- IV Series User's Manual (Monitor) -
A
Settings List
Sensor Setup screen
1. Image Optimization
Menu Description Setting range
Reference
page
Trigger Options
Sets an imaging timing of
a target.
Internal
Trigger interval:
1 to 10000 ms
(default value: 50 ms)
External
Trigger delay:
0 to 1000 ms
(default value: 0 ms)
4-8
Auto Brightness Adjustment
Automatically adjusts a
image brightness.
- 4-11
Focus Adjustment
Adjusts focus of the
sensor.
Manual focusing type
-
Auto focusing type
Automatic
Manual
4-12
Extended
functions
menu
Imaging Area Sets an imaging area.
Entire (default value)
Partial
4-17
Advanced
Brightness
Adjustment
Bright
Adjusts brightness of an
image manually.
Standard range type
(color)
1 to 100 (default value: 20)
Standard range type
(monochrome)
1 to 120 (default value: 20)
Short range type
1 to 120 (default value: 20)
Long rang type
1 to 100 (default value: 20)
4-18
Imaging
Mode
Select an imaging mode
of the sensor.
Normal (default value)
HDR
HighGain
4-18
Lighting
Select a lighting mode for
the built-in light.
OFF
Flash (default value)
Continuous
4-18
Color Filters
(color type only)
Applies the color lters if
an outline of a certain color
cannot be displayed when
an image is displayed in
monochrome display with
the color type sensor.
OFF (default value),
Red, Green, Blue, Cyan,
Magenta, Yellow
4-19
Digital Zoom
(monochrome type only)
Switches the digital zoom
to ON/OFF.
ON
OFF (default value)
4-19
