- IV Series User's Manual (Monitor) -
Checking the Package Contents
Wall mounting adapter
OP-87464
Wall mounting adapter x 1
Screw for the adapter x 2
Hexagon nut x 2
Same as accessories for monitors.
Optional parts in case of loss/damage.
Panel mounting adapter
OP-87465
Panel mounting
adapter x 1
Mounting screw (lateral) x 2
Mounting screw (front) x 4
“Mounting to a panel” (Page 2-10)
DIN mounting adapter
OP-87466
DIN mounting
adapter x 1
Mounting screw (lateral) x 2
“Mounting to the DIN rail” (Page 2-11)
1
Getting Started
