A-13
- IV Series User's Manual (Monitor) -
A
Settings List
Menu Description Setting range
Reference
page
Setup Adjustment 6-25
Tilt Correction
Shapes can be adjusted
to the correct shape if an
image displayed on the
monitor is distorted.
OFF (default value)
Vertical
Horizontal
6-38
Image Settings
Adjusts imaging for the
Tilt Correction.
Same as Image
Optimization
6-38
Rotate 180°
Displays the image
displayed on the monitor
by rotating 180°.
ON
OFF (default value)
6-40
Image Settings
Adjusts imaging for the
Rotate 180°.
Same as Image
Optimization
6-40
White Balance
(Color type only)
Adjusts a white balance
for the built-in camera of
the sensor.
- 6-41
Image Settings
Adjusts imaging for the
White balance.
Same as Image
Optimization
6-41
Program 6-25
Program Switch Method
Select a changing
method for programs.
Monitor/PC (default value)
External IN
6-42
Auto Focus Adj Pos
Sets whether or not
to share the adjusting
position for auto focus to
all programs.
Common
Individual (default value)
6-42
System 6-25
Sensor Information
Displays the model,
version, serial number,
MAC address, IP address,
and device name of the
sensor.
- 6-43
Initialize Sensor
Initializes the sensor
settings.
- 6-44
Update Sensor
Updates the operation
software of the sensor.
- 6-44
