A-10
- IV Series User's Manual (Monitor) -
A
Settings List
Menu Description Setting range
Reference
page
Monitor Environment 6-45
Language
Selects the language
to be displayed on the
monitor.
English
Japanese
Deutsch
Chinese (Simplied)
Chinese (Traditional)
Italian
French
Spanish
Portuguese
Korean
6-51
Time Sets date and time. - 6-51
Backlight
Backlight Brightness
Adjusts the brightness of
backlight on the monitor.
1 to 7 (default value: 5) 6-52
Auto Off
Sets the Auto off function
of backlight on the monitor
to Enable/Disable.
Enable
Disable (default value)
6-52
Auto Off Time Delay
Sets a time until the
back light turns off when
the Auto off function is
enabled.
30 sec
1 min (default value)
5 min
10 min
30 min
6-52
Touch Panel Calibration
Adjusts the position to be
tapped of the monitor.
- 6-52
System 6-45
Monitor Information
Displays the model,
version, serial number,
MAC address, and IP
address of the monitor.
- 6-53
Sensor Information
Displays a sensor
information.
- 6-43
Initialize Monitor
Initializes the settings of
the monitor.
- 6-53
Update Monitor
Updates the operation software
version of the monitor.
- 6-53
