A-9
- IV Series User's Manual (Monitor) -
A
Settings List
Monitor Settings screen
Menu Description Setting range
Reference
page
Sensor Connect
Selects a connection
method of the sensor and
monitor.
- 6-46
Direct/Network
Switches the connection
method of the sensor and
monitor.
Direct Connection
Network
Connection
6-46
Search Sensor
Searches for sensors on
the network and perform
their connection.
- 6-46
Specify Sensor
Species the IP address
of the sensor to connect.
- 6-46
Monitor Device Settings 6-45
Network
Settings
MAC Address
Displays the MAC
address for the monitor.
- 6-48
IP Address
Displays the IP address
of the monitor.
192.168.10.1
(default value)
6-48
Subnet Mask
Displays the subnet mask
of the monitor.
255.255.255.0
(default value)
6-48
Default Gateway
Displays the default
gateway of the monitor.
0.0.0.0
(default value)
6-48
Display
Settings
Manual Trigger
Sets the Manual Trigger
to enable/disable.
Enable (default value)
Disable
6-49
Update Image in RUN
Mode
Sets whether or not
to update an image
displayed on the monitor
during running.
ON (default value)
OFF
6-49
Tool Auto Tuning Guide
Sets the Tool Auto Tuning
Guide to Show/Hide.
Show (default value)
Hide
6-49
Touch
Screen
Lock
Touch Screen Lock
Sets Touch Screen Lock
function to enable/disable.
Enable
Disable (default value)
6-50
Password
Sets a password when
the Touch Screen Lock
function is enabled.
Up to 8 characters
(English and Japanese
single byte characters)
6-50
