- IV Series User's Manual (Monitor) -
A
Settings List
Menu Description Setting range
Reference
page
Sensor Image History
Displays the Sensor
Image History screen.
- 6-14
View
Displays the image
history in the sensor.
- 6-14
Batch Backup
Backs up the image
history in the sensor.
- 6-19
View
Displays the selected image
in full-screen in the monitor.
- 5-6
Save to USB Memory
Saves the displayed image
to the USB memory.
- 6-20
Auto Tuning
Performs the Tool Auto
Tuning based on the
displayed image.
AutoTune as OK
AutoTune as NG
5-20
Clear
Deletes the image history
in the sensor.
- 6-16
Image History Settings
Sets the condition of an image
to log as an image history.
All
NG only (default value)
6-17
USB Memory
Displays the USB
Memory screen.
- 6-18
Batch Backup
Backs up the sensor
settings and image history
into the USB memory.
Program Only
Prog.+Image Hist.
(default value)
6-19
Transfer Program Settings
Transfers the settings
backed up into the USB
memory to the sensor.
- 6-21
Option (Transfer All Settings)
Transfers the I/O polarity,
network settings and device
name simultaneously with
the settings data transfer.
Enable
(disabled after the transfer)
Disabled
(default value)
6-21
Screen Capture Settings
Saves the image
displayed on the monitor
into the USB memory as
an image data (bmp).
ON (default value)
OFF
6-23
RUN
Displays the run screen
(menu display OFF).
- 5-2
