A-7
- IV Series User's Manual (Monitor) -
A
Settings List
Menu Description Setting range
Reference
page
Sensor Setup
Displays the Sensor
Setup Menu screen.
- 6-7
Trig
Displays when the
external trigger is set.
- 4-7
Zoom
Sets the monitor to full-
screen mode. Zooming
in/out can be performed.
1.0x (default value)
1.5x
2.0x
3.0x
5-6
View
Tool View
Changes the display
method of the tool.
OFF
Window
Process 1 (default
value)
Process 2
5-7
Analysis
Displays the analysis
information (statistics/
histogram).
OFF (default value)
Statistics
Histogram
5-10
5-12
Sensor Setup Menu screen
Menu Description Setting range
Reference
page
Program
Switches the programs to
be set.
PROG_00 to PROG_31 6-8
Detail
Displays the sensor
program detail screen
-
6-12
6-13
(Master image)
Displays the master
image of the currently
selected program.
PROG_00 to PROG_31 6-7
(Program information)
Displays an information
of selected program.
-
6-12
6-13
Edit Edits a program name.
Up to 16 characters
(English and Japanese
single byte characters)
6-12
Copy
Copies the selected
program to unregistered
program.
- 6-12
Initialize
Initializes the program
settings.
- 6-13
Sensor Setup
Displays the Settings
Navigator screen.
- 4-1
Limit Adjustment
Adjusts the threshold of
selected tool.
0 to 100 5-14
Tool Auto Tuning
Displays the screen for
the Tool Auto Tuning.
- 5-15
Sensor Advanced
Displays the sensor
advanced screen.
- 6-25
