1-10
- IV Series User's Manual (Monitor) -
Checking the Package Contents
Intelligent Monitor
IV-M30
Monitor x 1
Stylus x 1
String for hanging the stylus x 1
Wall mounting adapter x 1
Screw for the adapter x 2
Hexagon nut x 2
Instruction Manual x 1
Starting Guide x 1
“Name and Function of Each Part” (Page 1-13)
“Mounting the Monitor” (Page 2-8)
“Cables” (Page 2-12)
Optional parts for the monitor
Monitor power cable
(M8 4pin - strand wire)
OP-87443 (2m)
OP-87444 (5m)
OP-87445 (10m)
Monitor power cable (M8 4pin - strand wire)
Protection sheet
OP-87463
Protection sheet x 1
“Attaching the protection sheet” (Page A-41)
USB memory (1GB)
OP-87502
USB memory x 1
Stylus
OP-87462
Stylus x 1
String for hanging the
stylus x 1
Same as accessories for monitors.
Optional parts in case of loss/damage.
1
Getting Started
