8-12
- IV Series User's Manual (Monitor) -
Dimensions
Optional parts for the monitor
Monitor power cable
OP-87443
(2m)
OP-87444
(5m)
OP-87445
(10m)
2000
5000
10000
φ
3.7
φ9.5
26.7
Protection sheet
OP-87463
t = 0.16
69.9
73.9
5
50.4
Stylus
OP-87462
φ7.6
φ5.6
94.7
Wall mounting adapter
OP-87464
8.5
96.9
4.5
48
Panel mounting adapter
OP-87465
18.5
109
119
DIN mounting adapter
OP-87466
9.9
30.7
81.3
107
8
Specications
