8-7
- IV Series User's Manual (Monitor) -
Dimensions
With dome attachment
Installed distance : 0 to 50 mm from the front of the dome attachment
Compatible sensor : Standard range type/Short range type
62
34.6
φ134
Distance from WD reference surface
With polarizing lter attachment
φ56
5
32
Distance from WD reference surface
Optional parts for the sensor
Dome attachment
IV-D10
φ134
90.4
8
Specications
