8-6
- IV Series User's Manual (Monitor) -
Dimensions
Sensor
IV-500C
IV-500CA
IV-150M
IV-150MA
IV-500M
IV-500MA
IV-2000M
IV-2000MA
Mounting
adapter
(102)
R50
R50
(108)
50
57.4
32.4
56
81.5
50
10.5 10.5
610.5
20.5
41
(Depth 6mm)
3-M3
52
0.4
Focusing position
adjustment screw
(MF type only)
WD reference surface
45.5 25
58
20
4-M4
(Depth 6mm)
1/4-20UNC
(Depth 6mm)
Dimensions
8
Specications
