- IV Series User's Manual (Monitor) -
Specications
Intelligent Monitor
Model IV-M30
Display 3.5" TFT color LCD 320 x 240 dot (QVGA)
Backlight
Method White LED
Duration Approx. 50,000 hours (25 ˚C)
Touch panel
Method Analog resistive
Actuating force 0.8N or lower
Indicators PWR, SENSOR
Ethernet
*1
Standard 100BASE-TX/10BASE-T
Connector M12 4pin connector
Languages
Japanese / English / Deutsch / Chinese (Simplied) /
Chinese (Traditional) / Italian / French / Spanish / Portuguese /
Korean
Expanded memory USB memory*
2
Rating
Power voltage DC 24V ± 10% (including ripple)
Consumption
current
0.2A or lower
Environmental
resistance
Ambient
temperature
0 to +50°C (No freezing)
Relative humidity
*3
35 to 80%RH (No condensation)
Vibration
10 to 55 Hz, 1.5 mm double amplitude, 2 hours each for X, Y,
and Z axes
Drop impact
resistance
1.3m over the concrete (2 times each in the arbitrary direction)
Enclosure rating IP40
Material Polycarbonate
Weight Approx. 180g
*1 This is dedicated for connection with IV Series sensor.
*2 Use the KEYENCE recommended product.
*3 If the ambient temperature is over 40˚C, use it in the absolute humidity of 40˚C 80% RH or lower.
8
Specications
