- IV Series User's Manual (Monitor) -
Specications
Model IV-500C
IV-500CA
IV-500M
IV-500MA
IV-150M
IV-150MA IV-2000M
IV-2000MA
Output
Open collector output NPN/PNP is switchable, N.O./N.C. is switchable
For open collector NPN output : Maximum rating 26.4V 50mA,
remaining voltage 1.5V or lower
For open collector PNP output : Maximum rating 26.4V 50mA,
remaining voltage 2V or lower
Outputs 4 outputs (OUT1 to OUT4)
Function
Enable by assigning the optional functions
Assignable functions :
Total judge result, RUN, BUSY, Error, Position adjustment result,
Judge result of each tool, Logical operation result of each tool
Ethernet
*10
Standard 100BASE-TX/10BASE-T
Connector M12 4pin connector
Network function FTP client, EtherNet/IP, PROFINET
Rating
Power
voltage
DC 24V ± 10% (including ripple)
Consumption
current
0.6A or less
Environmental
resistance
Ambient
temperature
0 to +50°C (No freezing)
Relative
humidity
35 to 85%RH (No condensation)
Vibration 10 to 55 Hz, 1.5 mm double amplitude, 2 hours each for X, Y, and Z axes
Shock
resistance
500m/s
2
6 different directions in 3 times
Enclosure
rating
*11
IP67
Material
Main unit case : Aluminum die-casting, Packing : NBR, Front Cover : Acrylic,
Mounting adapter : POM
Weight Approx. 270 g
*1 The focusing position can be automatically adjusted at the time of installation. Disabled during the
operation.
The focusing position can be registered by programs.
*2 Tools can be installed by programs.
*3 Saves to the memory in the sensor.
The images saved in the sensor can be backed up to the USB memory installed to the intelligent
monitor (IV-M30) or to the PC by the software for IV (IV-H1).
*4 70 images when using the FTP client function
*5 210 images when using the FTP client function
*6 This can be displayed on the intelligent monitor (IV-M30) or by the IV software (IV-H1).
*7 Color type only.
*8 Monochrome type only.
*9 This function can be used with the software for IV (IV-H1).
*10 This is for connection with the intelligent monitor (IV-M30) or the IV software (IV-H1).
*11 Except when the polarizing lter attachment (OP-87436/OP-87437) is mounted.
