6-45
- IV Series User's Manual (Monitor) -
Setting the Advanced Monitor Information
Monitor Settings
The section explains the monitor settings displayed
by tapping the [Monitor Settings] button with the
state that the menu display of the monitor is set to
ON.
Sensor Connect
Performs the settings for connecting with the
sensor.
“Sensor Connect” (Page 6-46)
Monitor Device Settings
Network Settings
Performs the network settings of the monitor.
“Network Settings” (Page 6-48)
Display Settings
Performs the settings for the screens and
buttons to be displayed on the monitor.
“Display Settings” (Page 6-49)
Touch Screen Lock
Sets to prevent the incorrect operation of the
monitor.
“Touch Screen Lock” (Page 6-50)
Monitor Environment
Language
Selects the language to be displayed on the
monitor.
“Language” (Page 6-51)
Time
Conrms or changes the time set in the monitor.
“Time” (Page 6-51)
Backlight
Sets the backlight of the monitor.
“Backlight” (Page 6-52)
Touch Panel Calibration
Adjusts the position to be touched of the
monitor.
“Touch Panel Calibration” (Page 6-52)
System
Monitor Information
Displays the information set in the monitor.
“Monitor Information” (Page 6-53)
Initialize Monitor
Initializes the information set in the monitor.
“Initialize Monitor” (Page 6-53)
Update Monitor
Updates the software version of the monitor.
“Displaying the Sensor Image History
screen” (Page 6-14)
Setting the Advanced Monitor Information
6
Useful Features/Various Functions
