- IV Series User's Manual (Monitor) -
Sensor Image History (Conrming the Images whose Status Result is NG)
Changing the logging conditions of
the image history
Sets the logging condition (storage condition) for
the image history.
1
Display the Sensor Image History screen.
Display the Sensor Image History screen from
the Sensor Setup Menu screen.
The [Logging Settings] can be set only when
it is selected from the Sensor Setup Menu
screen.
“Displaying the Sensor Image History screen”
(Page 6-14)
2
Tap the [Logging Settings] button.
3
Select a logging condition.

All ..................... Saves all the images to the
image history regardless of
the status result.

NG only ............ Only saves the images whose
status result is NG to the
image history.
4
Tap the [OK] button.
The system returns to the Sensor Setup Menu
screen.
