Changeover for a Target (Program Functions)
When the [External IN] is selected in the Program Switch Method
1
Start the run mode.
“Starting an Operation” (Page 5-2)
2
Select the program number to which the product to be judged is registered with the status
of the input line.
Change the input lines IN2 to IN6 which were assigned to bit0 to bit4 in the input settings (Page 6-26)
to the following statuses and maintain the settings. Start the run mode with the new program number.
Program
number
bit4
(MSB)
bit3 bit2 bit1
bit0
(LSB)
Program
number
bit4
(MSB)
bit3 bit2 bit1
bit0
(LSB)
PROG00 OFF OFF OFF OFF OFF PROG16 ON OFF OFF OFF OFF
PROG01 OFF OFF OFF OFF ON PROG17 ON OFF OFF OFF ON
PROG02 OFF OFF OFF ON OFF PROG18 ON OFF OFF ON OFF
PROG03 OFF OFF OFF ON ON PROG19 ON OFF OFF ON ON
PROG04 OFF OFF ON OFF OFF PROG20 ON OFF ON OFF OFF
PROG05 OFF OFF ON OFF ON PROG21 ON OFF ON OFF ON
PROG06 OFF OFF ON ON OFF PROG22 ON OFF ON ON OFF
PROG07 OFF OFF ON ON ON PROG23 ON OFF ON ON ON
PROG08 OFF ON OFF OFF OFF PROG24 ON ON OFF OFF OFF
PROG09 OFF ON OFF OFF ON PROG25 ON ON OFF OFF ON
PROG10 OFF ON OFF ON OFF PROG26 ON ON OFF ON OFF
PROG11 OFF ON OFF ON ON PROG27 ON ON OFF ON ON
PROG12 OFF ON ON OFF OFF PROG28 ON ON ON OFF OFF
PROG13 OFF ON ON OFF ON PROG29 ON ON ON OFF ON
PROG14 OFF ON ON ON OFF PROG30 ON ON ON ON OFF
PROG15 OFF ON ON ON ON PROG31 ON ON ON ON ON
When the polarity (Page 6-28) is [NPN] ON : the state shorted with 0 V line
OFF : Open
When the polarity (Page 6-28) is [PNP] ON : the state that voltage is applied
OFF : Open
For details of the controlling method and the timing chart, refer to “Changing Over” (Page 7-7).
6
Useful Features/Various Functions
