6-8
- IV Series User's Manual (Monitor) -
Changeover for a Target (Program Functions)
Overview of the program functions
The sensor can save the judgment condition set in
the settings navigator as a program up to 32 types
(32 products).
By reading the judgment condition which has been
saved according to each product, changeover can
be done easily.
Sensor
PROG31 : Product XX
• • •
PROG02 : Product C
PROG01 : Product B
PROG00 : Product A
Settings Navigator
Imaging settings
*1
Master image
Tool settings
*2
Output Assignment
Sensor Advanced
Environmental
Setup Adjustment
Switching programs
*1 The auto focus type includes the focusing
position.
*2 Including the threshold of each tool.
Things can be performed with
the program functions
Saves 32 types (32 products) of judgment
conditions (programs).
“Chapter 4 Settings Navigator (Setting the
Judgment Condition)” (Page 4-1)
Reads and operates the saved program.
“Using the program functions (changing over)”
(Page 6-10)
Selects the reading method of the program.
“Program Switch Method” (Page 6-42)
Names the judgment conditions (programs).
“Editing a program name” (Page 6-12)
Copies and uses the judgment conditions (programs).
“Copying a program” (Page 6-12)
Returns the judgment conditions (programs) to
the status before setting.
“Initializing a program” (Page 6-13)
Changeover for a Target
(Program Functions)
6
Useful Features/Various Functions
