6-3
- IV Series User's Manual (Monitor) -
List of the Useful Features
Items Things you want to do Useful functions Description
Reference
page
Display
Conrm images hidden under
the menu or title
Zoom button
The menu and title can be
hidden and the image will be
displayed in full-screen.
5-5
Zoom in/out the images Zoom button
The zoom ratio can be
changed to x 1/x 1.5/x 2/x 3.
5-6
Adjust the brightness of the
backlight
Backlight
The brightness of the backlight
can be adjusted between 7 levels.
6-52
Dim the backlight when not in
use
Backlight
The monitor can be set to dim
automatically when not used
for a specic period of time.
6-52
Change the display language Language
The language can be changed
to Japanese, English,
Deutsch, Chinese (Simplied),
Chinese (Traditional), Italian,
French, Spanish, Portuguese
or Korean.
6-51
Hide the trigger button
Manual Trigger
The [Trig] button displayed
when the external trigger is
selected can be hidden.
6-49
Make the screen update faster
Update Image in
RUN Mode
If the image is not need to be
displayed, the screen update
can become faster by setting to
display the status result only.
6-49
