5-30
- IV Series User's Manual (Monitor) -
Tool Auto Tuning (Automatically Adjusting the Judgment Condition)
10
After the registration is completed, tap the
[Save] button.
The conrmation dialog appears.
11
Tap the [OK] button.
Adjusted results will be reected and the
information dialog appears.
12
Tap the [OK] button.
By tapping the [Saving to the USB memory]
button, the result of Tool Auto Tuning can be
saved in the USB memory as a registration
information and can be reused.
The system returns to the Sensor setup menu
screen.
5
Operating/Adjusting
