Tool Auto Tuning (Automatically Adjusting the Judgment Condition)
5
Tap the [Use the registered information le]
button.
The import screen for registration information
le appears.
6
Select the registered information le (*.ivt)
and tap the [OK] button.
Select the le to
be imported
Files with the formats other than ivt format
cannot be used.
If the conrmation dialog appears, change
the registration le to be imported according
to the message.
For the monitor operation software version
R1.10, this le cannot be use. Update the
software to the latest version.
For details of selecting the les in the USB
memory, refer to “Selecting the le in the USB
memory” (Page 3-17).
The conrmation screen opens.
7
Tap the [Go] button.
Re-adjustment is performed by using the
registered information le.
The information dialog appears.
8
Check the changes made by the re-
adjustment and tap the [OK] button.
Changed
settings
The registration menu screen for the Tool Auto
Tuning opens.
9
To add images, register the OK/NG images.
“Registering the OK/NG images to be used
for the Tool Auto Tuning” (Page 5-18)
5
Operating/Adjusting
