5-2
- IV Series User's Manual (Monitor) -
Starting an Operation
Starts an operation in accordance with the program created with the Settings Navigator.
The sensor can be independently operated.
Turning on the power and starting
an operation
1
Turn on the power of the sensor and monitor.
2
Conrm that the operation screen opens.
If the image or status result does not update,
refer to
“Troubleshooting” (Page A-19).
When the power of the monitor is turned on for
the rst time, the initial settings screen opens.
“Operation when the Power is Turned on”
(Page 3-5)
Exiting the sensor settings and
starting an operation
1
Exit the settings of the sensor, such as
Settings Navigator.
“Finishing the Settings Navigator” (Page 4-5)
The Sensor Setup Menu screen opens.
2
Tap the [RUN] button.
The run screen opens and the operation starts.
If the image or status result does not update,
refer to “Troubleshooting” (Page A-19).
Starting an Operation
5
Operating/Adjusting
