4-61
- IV Series User's Manual (Monitor) -
Setting the Output Assignment
1
Start the Settings Navigator.
“Starting the Settings Navigator” (Page 4-3)
2
Display the main screen for the Output
Assignment.
“Settings Navigator screen and operation ow”
(Page 4-4)
3
Tap the item name of output line to perform
output assignment and select the output item.
4
Finish the Settings Navigator.
“Finishing the Settings Navigator” (Page 4-5)
1. Image Optimization 2. Master Registration 3. Tool Settings 4. Output Assignment
Output Assignment Extended functions
4
Settings Navigator (Setting the Judgment Condition)
