Extended functions of the Color Area/Area tool
Items Description Setting range
Default
value
Advanced Color
Extraction
(For color type)
Advanced Brightness
Extraction
(For monochrome type)
Color type
Species a color to be extracted as HSB
(H: Hue, S: Saturation, B: Brightness).
H (hue)
0° to 359°
(both starting point
and ending point)
S (saturation)
0 to 255
B (Brightness)
0 to 255
-
Monochrome type
Species brightness value to be
extracted.
0 to 255 -
to Live Image
A color/brightness range to be extracted
can be set on the Live image of the target.
- -
Tool Name
An arbitrary name such as name of a
target can be set to tools. Tool names can
be checked on the run screen.
“Chapter 5 Operating/Adjusting” (Page 5-1)
Up to 8 characters
in one byte English
characters can be set.
(None)
Fixed Reference Area
Select a condition which the matching rate
of the Color Area/Area is 100%.
Disable
Matches the area
extracted from the
master image as the
criteria of a rate of
100%.
Enable: Large
Matches 1/10th of
the total sensor view
as the criteria of a
rate of 100%.
Enable: Small
Matches 1/100th of
the total sensor view
as the criteria of a
rate of 100%.
Disable
