assembly Instructions

44
Self drill screw
s10b (x20)
0.47”
12 mm
mbl (x1)mtl (x1)mpn (x2)
s10b
Right Door
Porte Droite
Puerta Derecha
Rechte Tür
Rechter Deur
Porta Destra
Porta Direita
s10b x 1
Left Door
Porte Gauche
Puerta Izquierda
Linke Tür
Linker Deur
Porta Sinistra
Porta Esquerda
1
2
s10b
s10b
1
s10b
2
s10b x 1
mpn
mtl
mpn
mbl
45
smdh (x4)
s13b (x20)
0.47”
12 mm
s13b
s13b
x4
1
x4
2
Right Door
Porte Droite
Puerta Derecha
Rechte Tür
Rechter Deur
Porta Destra
Porta Direita
Left Door
Porte Gauche
Puerta Izquierda
Linke Tür
Linker Deur
Porta Sinistra
Porta Esquerda
