KERN & Sohn GmbH Ziegelei 1 D-72336 Balingen E-Mail: info@kern-sohn.com Phone: +49-[0]7433- 9933-0 Fax: +49-[0]7433-9933-149 Internet: www.kern-sohn.com Operating manual Electronic bathroom scales KERN MPI Version 1.
GB KERN MPI Version 1.0 2017-07 Operating manual Bathroom Balance Contents 1 Technical data ................................................................................................... 3 2 Declaration of conformity ................................................................................. 4 3 Basic Information (General) ............................................................................. 4 3.1 Proper use ........................................................................
1 Technical data KERN MPI 200K-1 Readability (d) 0.1 kg Weighing range (max) 200 kg Accuracy +- 0.5% +- 0.1kg Weighing Units kg, lb Warm-up time 10 min. Operating temperature Height of digits (mm) Humidity of air Battery -10° C …. + 40° C 30 max. 80 % (not condensing) 4 x 1.5 V AAA Operating period: 20 h Auto-Off: 15 sec. Dimensions (B x D x H) mm 433 x 370 x 34.
2 Declaration of conformity The current EC/EU Conformity declaration can be found online in: www.kern-sohn.com/ce 3 Basic Information (General) 3.1 Proper use This balance is used to calculate the weight of people in the private sphere. Utilisation of this balance in the medical field is not permissible. The weighing process requires that the person stands on the weighing plate in a way that provides even weight distribution over the entire weighing plate.
4 Basic Safety Precautions 4.1 Pay attention to the instructions in the Operation Manual Attention: Stepping on the edge of the weighing plate may cause tilting of balance or fall of person. Carefully read this operation manual before setup and commissioning, even if you are already familiar with KERN balances. 5 Transport and storage 5.1 Testing upon acceptance When receiving the appliance, please check packaging immediately, and the appliance itself when unpacking for possible visible damage. 5.
The occurrence of electric fields or electrostatic charge may result in major display deviations (incorrect weighing results). In that case, the location must be changed. 6.2 Unpacking Take the whole balance out of their packaging and place them at the intended position. Scope of delivery: Balance Operating manual 4 Leveling feet 6.3 Battery operation “bAtt“ on the display indicates that the battery load status is too low. Replace batteries as quickly as possible with a new set.
8 Using the balance The weighing process requires that the person stands on the weighing plate in a way that provides even weight distribution over the entire weighing plate. Remain as upright and still as possible during the weighing process. When a stable weighing value has been reached you can read the weighing result. After leaving the weighing platform the scales will turn off automatically.
9 Servicing, maintenance, disposal 9.1 Cleaning Do not use aggressive cleaning agents (solvents or similar) but only a damp cloth with mild soapsuds, or household cleaner. Ensure that no liquid gets inside the unit and rub with a soft, dry cloth. Loose dirt can be removed carefully with a brush or hand-held vacuum cleaner. Balance must not be tilted or rotated for cleaning, as damage may occur. Remove dirt immediately. 9.
11 Instant help Help: Fault Possible cause The displayed weight is permanently changing • Draught/air movement • • • Table/floor vibrations Weighing plate has contact with other objects Electromagnetic fields / static charging (choose different location/switch off interfering device if possible) • The display of the balance is not at zero • • Great fluctuations in temperature.
