Data Sheet

KERN FFN3K1IPM
Allround-Tischwaage, geschützt durch Edelstahl und Schutzklasse IP65, auch mit Eichzulassung
[M]
Measuring system
Adjustment options: External calibration
Linearity: 1 g
Readout [d]: 1 g
Recommended adjusting weight: 3 kg (M3)
Reproducibility: 1 g
Resolution: 3000
Stabilisation time: 2 s
Tare range: -2999000 mg
Warm up time: 10 min
Weighing range [Max]: 3 kg
Weighing system: Strain gauge
Weighing units: g kg
Display
Display digit height: 2,500 cm
Technical data about verification
Minimum load [Min]: 20 g
Periodic Verification for Italy: 969-112
Verification approval conforming
to 2014/31/EU:
yes
Verification by KERN possible: yes
Verification class: III
Verification value [e]: 1 g
Environmental conditions
Maximum humidity: 80 %
Maximum operating temperature: 40
O
C
Minimum ambient temperature: -10
O
C
Minimum humidity: 0 %
Power supply
Charging time: 12 h
Input voltage: 110 V - 230 V AC
n/a: CH EURO UK US
n/a: Mains adapter external
Power supply
Operating time (Backlight off): 50 h
Operating time (Backlight on): 30 h
Service
Adjustment at the location of installation:961-247
DAkkS Certificate: 963-127
Verification: 965-227
Category
Brand: KERN
Category: Balances
Product Group: Bench scale
Packaging & shipping
Delivery: 24 h
Dimensions packaging (WxDxH): 395 x 295 x 205 mm
Gross weight: 4,722 kg
Net weight: 3,820 kg
Shipping method: Parcel service
UN number: 2800
Construction
Dimensions housing (WxDxH): 230 x 300 x 130 mm
Level indicator: yes
Material weighing plate: stainless steel
Overall dimensions mounted
(WxDxH):
230 x 300 x 130 mm
Revolving screw feet: yes
Weighing surface (WxD): 230 x 190 mm
