Data Sheet

KERN DE60K10D
Langjähriges Erfolgsmodell mit staub- und spritzwassergeschüt ztem Auswer tegerät
Measuring system
Adjustment options: External calibration
Linearity: 30 g | 60 g
Readout [d]: 10 g | 20 g
Recommended adjusting weight: 60 kg (M1)
Reproducibility: 10 g | 20 g
Resolution: 3 3.000
Stabilisation time: 2,500 s
Warm up time: 10 min | 10 min
Weighing range [Max]: 30 kg | 60 kg
Weighing system: Strain gauge
Weighing units: dwt kg lb mo oz ozt tl (HK) tl
(Tw) tol
Display
Display digit height: 2,500 cm
Counting
Counting resolution: 3000
Mininum piece weight at piece
counting (Laboratory:
20 g
Mininum piece weight at piece
counting (Normal):
200 g
Functions
Counting function: yes
Percentage determination: yes
Vibration-free weighing (Animal
weighing program):
yes
Environmental conditions
Maximum humidity: 80 %
Maximum operating temperature: 35
O
C
Minimum ambient temperature: 5
O
C
Power supply
Charging time: 10 h
Input voltage: 220 V - 240 V AC 50 Hz
n/a: CH EURO UK US
n/a: Mains adapter external
Power supply
Operating time: 12 h
Operating time (Backlight off): 30 h
Operating time (Backlight on): 15 h
Rechargeable battery: Rchrg. battery optional
Service
Adjustment at the location of installation:961-249
DAkkS Certificate: 963-129
Category
Brand: KERN
Category: Balances
Product Group: Platform scale
Packaging & shipping
Delivery: 24 h
Dimensions packaging (WxDxH): 515 x 385 x 135 mm
Gross weight: 5,590 kg
Net weight: 4,740 kg
Shipping method: Parcel service
Construction
Cable length of display device: 1,400 m
Dimensions housing (WxDxH): 315 x 305 x 75 mm
Dimensions of display device
(WxDxH):
225 x 110 x 60 mm
Dimensions of weighing plate
(WxDxH):
318 x 308 x 75 mm
Material weighing plate: stainless steel
Weighing surface (WxD): 318 x 308 mm
