2.3 PRELIMINARY OPERATIONAL CHECK
A simple operational check after unpacking and before equipment installation is advisable to
ascertain whether the power supply has suffered damage resulting from shipping.
Refer to Figures 2-1, 2-2 and 3-1 for location of operating controls and electrical connections.
Table 3-1 explain the functions of operating controls/indicators. Refer to PAR. 3.3 for a descrip-
tion of basic operating techniques.
2.3.1 PRELIMINARY OPERATIONAL CHECK USING ANALOG CONTROL
1. With POWER switch set to off position, verify that the power-up switches at the top cover are
set to the factory default positions shown in Figure 2-3. This establishes GPIB address 6,
standalone operation, Voltage mode, Analog Input enabled and internal ±current limits
enabled and set to maximum.
NOTE: The unit is shipped with load type set to Active (for inductive loads). If necessary, refer
to 3.3.7 for an explanation of load types and to PAR. 3.3.2.1 to change the load type.
The logic for Remote on/off input at pin 2 of the Trigger port is set to high (1) or open
circuit for output on, low (0) or short circuit for output off.
TABLE 2-12. IEEE 488 PORT INPUT/OUTPUT PIN ASSIGNMENTS
CONNECTOR PIN SIGNAL NAME FUNCTION
IEEE 488
PORT
J5
1D
I01 I/O Line
2D
I02 I/O Line
3D
I03 I/O Line
4D
I04 I/O Line
5 EOI End or Identify
6 DAV Data Valid
7 NRFD Not Ready for Data
8 NDAC Not Data Accepted
9 IFC Interface Clear
10 SRQ Service Request
11 ATN Attention
12 SHIELD Shield
13 D
I05 I/O Line
14 D
I06 I/O Line
15 D
I07 I/O Line
16 D
I08 I/O Line
17 REN Remote Enable
18 GND Ground (signal common)
19 GND Ground (signal common)
20 GND Ground (signal common)
21 GND Ground (signal common)
22 GND Ground (signal common)
23 GND Ground (signal common)
24 LOGIC GND Logic Ground
