GENERAL (ENVIRONMENTAL) CHARACTERISTICS
Temperature operating 0 to +50 deg C Full rated load
storage -20 to +85 deg C
Cooling Two internal fans intake from the front, exhaust to the rear
Humidity 0 to 95% RH non-condensing
Shock 20g. 11msec ±50% half sine non-operating
Vibration 5-10HZ: 10mm double amplitude 3 axes, non-operating
10-55HZ: 2g 3 axes, non-operating
Altitude sea level to 10,000 feet
Safety Certification a-c power UL 3101-1 and EN 6101-1 Pending
PHYSICAL CHARACTERISTICS
Dimensions English 5.25' X 19" X 21.5" H X W X D
metric 133.3mm X 482.6mm X 546.1mm H X W X D
Weight, 1000W models English 53 lbs
metric 24.1Kg
Connections Source power 3-pin IEC connector
Load connections Nickel-plated copper bus bars With 1/4-20 threaded standoff.
Sensing Output
Terminal Block
7-pin terminal block Default: 3 links installed for local sensing and
ground network connected.
Analog I/O control
port
15-pin D female See Figure 2-1, Table 2-11.
PAR/SER CTRL IN
port
8-pin mini DIN connector See Figure 2-1, Table 2-8.
PAR/SER CTRL OUT
port
4-pin mini DIN connector See Figure 2-1, Table 2-7
PAR/SER PROT IN
port
8-pin phone jack See Figure 2-1, Table 2-9
PAR/SER PROT OUT
port
8-pin phone jack See Figure 2-1, Table 2-10
EXT PROT port 6-pin phone jack See Table 2-5
Primary digital port 24-pin GPIB connector IEEE 488 port - See Table 2-12
Secondary digital
ports
6-pin phone jack RS 232 port - See Table 2-6
5-pin mini DIN female connector IEEE 1118 port - See Table 2-3
External Trigger 4-pin stereo audio phone jack See Table 2-4
TABLE 1-2. BOP GENERAL SPECIFICATIONS (Continued)
SPECIFICATION RATING/DESCRIPTION CONDITION
