Technical data


Network monitoring
Configure up to 100 network devices (BASIC: 3 devices). Network services of each device, which should be
monitored, can be assigned (ICMP or TCP ports).
The AlarmManager periodically checks, if the specified services on the servers are available.
The request interval can be set between 60 and 999 seconds. Note that the alarm will be triggered after 3
failed attempts.
By pressing the Kentix-Check-Button the connection to the selected service can be tested. A total of 50
services can be configured (BASIC: 3 services).
The AlarmManager (PRO only) can receive incoming SNMP-Traps as alarms. These will be sent to the users
which are configured to be notified of always-active alarms. Therefore OIDs can be assigned to each
network device. The retrigger time specifies the period of time after which the alarm can trigger again.
4.11.Settings - AlarmManager-PRO only
Network Cameras
The AlarmManager-PRO can control cameras in its network to start the recording of a video or picture
(depends on the camera features). Add the IP cameras to the according zone and enter the connection data
of the camera. The command to start a recording can be found in the cameras manual.
Enter the command as an URL without the IP-address in the HTTP command field (e.g. „/command=...“).#
For Mobotix and AXIS cameras predefined commands can be selected via the pulldown menu.
Check the camera setup by pressing the Kentix-Check-Button.
I/O Modules
The AlarmManager-PRO can be extended with up to 6 additional digital input and outputs modules (KIO7052
or KIO7053).
With these it is possible to monitor up to 96 more alarms e.g. air-conditioning-systems, extinguishing
systems, UPSs or other alarm detection systems.
For configuration regard the instructions in the „Enhancements“ section and the corresponding data sheets.
IP alarm forwarding (VdS 2465)
It is possible to connect the AlarmManager-PRO to a control center, which communicates over TCP
connections using the VdS 2465 protocol.
SMS alarm forwarding
It is possible to connect the AlarmManager-PRO to a control center, which can receive alarms via SMS.
