Technical data



4.10.Settings - AlarmManager-BASIC and -PRO

General Settings

System name

Enter the name of the system and choose the active state.

Regional settings

This settings allow to choose the timezone and the temperature unit.

Security

Webinterface always needs authentication. This prevents the system state to be accessed by unauthorized

users.

Backup folder

The path to the backup files of the AlarmManager‘s configuration is set here.

Alarm behavior

Alarm functions

Set the behavior of the AlarmManager for pending alarms here. The arming delay makes it possible to set a

timespan between arming and alarm triggering.

Signaling

The acoustic feedback (buzzers of AlarmManager and MultiSensors) and the feedback of the LEDs can be

activated or deactivated as needed, except the CO-alarming. A CO-alarm always triggers all buzzers for the

specified buzzer time.

E-Mail, SNMP & GSM

E-Mail

For e-mail notifications an account can be configured with or without user credentials. Depending on the E-

mail server, setting an encryption method might be necessary. When choosing the encryption mode

(STARTTLS / SSL) the required port will be set to the according default port. The port can be changed if

needed.#

Enter the IP-address of the e-mail server and the sender address here. #

It is possible to resolve DNS addresses to the according ip by hitting the button „DNS -> IP“.

Via the Kentix-Check-Button a test e-mail with the entered configuration can be sent.

SNMP - Monitoring

The AlarmManager supports full SNMP-functionality, therefore alarms can be sent as traps. Additionally the

AlarmManager can be configured for requests via network monitoring systems. For this purpose you can

download a MIB (Management Information Base) for the SNMP host.

GSM settings

Enter the mobile number and PIN of the SIM card.

Page  (04-2015, subject to change) kentix.com15

NOTE!

The test e-mail is sent to the e-mail-address of the first user. In case of an error please check, whether an

e-mail-address has already been configured for this user. Also take care of possible restrictions (routing/

firewalls) in your network and synchronize data like encryption and communication port with the

responsible persons.
