Key Description Qty Part Number Key Description Qty Part Number
67-1 Left Door (SS) 1 50600060C 96 End Cap, Left Side Shelf 1 30800205C
67-2
Left Door (Carbon Grey
Metallic)
1 50600060CB 97 Left Side Shelf 1 41500030
68 Side Burner Hose Fixed Bracket 2 50600085 98 Motor 1 50600210
69-1 Left Side Panel (SS) 1 50600045C 99 Rotisserie Rod 1 50600206
69-2
Left Side Panel (Carbon Grey
Metallic)
1 50600045CB 100 Fork 2 50600207
70 Tank Baffle 2 50600074C 101
Rotisserie Collar, Flat Head Set
Screw
1 50600209
71 Transformer 1 41500216 102 Shaft Collar 1 50600208
72 Three legs power line 1 50600229 103 Lid Rubber Bumper, Front 2 30800233
73 Pulse Decoration Box 2 30800246 104 Lid Rubber Bumper, Back 2 40800107
74 Wire Slot C 1 50600049 105 Temperature Gauge 1 30800207
75 Gas Tank Holder 1 30800253C 106 Temp Gauge Bezel 1 30800208
76-1 Back Panel (SS) 1 5060054C 107 Logo 1 30800209
76-2
Back Panel (Carbon Grey
Metallic)
1 5060054CB 108 Rotate Rod, Lid 2 40800108
77 Hole Grommet 3 30800245 109 Right Lid Handle Seat 1 30800247C
78 Electronic Ignition Module 2 61200215 110 Left Lid Handle Seat 1 30800248C
79 Main Burner Electrode L345 1 50600219 111 Lid Handle Spacers 2 30800259C
80 Main Burner Electrode L500 1 50600220 112 Cotter Pin 7 110050
81 Main Burner Electrode L715 1 50600223 113 Lid Handle 1 50600006C
82 Main Burner Electrode L560 1 50600222 114-1 Lid (SS) 1 50600002C
83 Main Burner Electrode L405 1 50600221 114-2 Lid (Carbon Grey Metallic) 1 50600002CB
84 Drip Tray 1 50600014C 115 Rear Panel, Rotisserie Burner 1 50600029
85 Lamp Seat 2 41500021 116 Lamp 2 41500218
86 Thermocouple Bracket 1 50600028 117 Light Bulb 2 41500218-1
87 Motor Support Bracket 1 50600026 118 Rotisserie Burner 1 50600080
88 Motor Support 1 50600027 119 Wire Slot A 1 50600013
89 Main Burner 5 30800086 120 Wire Slot B 2 41500015
90 Fascia, Left Side Shelf 1 41500044 121 Warming Rack 1 50600204
91 Igniter Wire, Side Burner 1 41500213 122 Cooking Grate 3 50600205C
92 Side burner bracket C 1 41500040 123 Heat Diffuser 5 41500013
93 Side Burner Base 1 41500036 124
Double Igniter Wire, Rotisserie
Burner
1 50600224
94 Cooking Grid, Side Burner 1 41500203 125 Firebox 1 50600008C
95 Side Burner 1 41500224
Not Pictured
Hardware Pack 1 50600330C
Manual 1 50600322C

18 • 146.48591710
PART
S
LI
S
T
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from:
Those on
y
our
p
articular
g
rill model. However
,
the method of assembl
y
remains the same.:
If you are missing hardware or have
damaged parts after unpacking grill,
call 1-888-287-0735 for replacement.
To order replacement parts after using grill,
call 1-844-553-6667.
