Key Description Qty Part Number Key Description Qty Part Number
1 Lid, Side Burner 2 41500041 35 Regulator With Fuel Gauge 1 50600233C
2 Rotate Rod, Side Burner 2 41500205 36 Control Knob Bezel 7 40900036
3 End Cap, Right Side Shelf 1 30800206C 37
Control Knob Bezel, Rotisserie
Burner
1 50403001
4 Right Side Shelf 1 50600033C 38 Control Knob, Rotisserie Burner 1 50600218
5 Cooking Grid, Side Burner 1 50600203 39 Control Knob, Searing Burner 1 50600217
6 Searing Burner Base 1 50600036 40 Control Knob 6 30800219
7 Drip Cup ,Searing Burner 1 50600039 41 Bottom Shelf 1 50600072C
8
Double Igniter Wire, Searing
Burner
1 50600225 42 Top Magnet Box 1 50600057
9 Fascia, Right Side Shelf 1 50600041C 43 Magnet 4 40200094
10 Searing Burner 1 50600081 44 Bottom Magnet Box 1 50600076C
11 Control Panel 1 50600019 45 Caster 2 30800238
12 Control Panel Inner Panel 1 50600023 46 Caster with Brake 2 30800237
13 Led Light Strip 1 50600230 47 Cart Support Angel Bar 2 50600058
14 Ground Wire 1 61300096 48 Gas Tank Tray Brackets 2 30800108C
15 Control Panel Glass 1 50600202C 49 Slider Bar 2 30800252C
16 Pulse ground wire 2 30800244 50
Gas Tank Tray
1 30800112C
17 Light Switch Seat 1 41500221 51 Motor Support 1 50600089C
18 Waterproof Switch 2 41500220 52 Rotisserie Rod Bracket 1 50600088C
19 Gas Valve, Side Burner 1 41500208 53 Drip Box 1 30800082C
20 Thermocouple Assembly 1 50600214 54 Door Bracket 1 50600056
21 Gas Hose B 1 50600215 55-1 Right Side Panel (SS) 1 50600051C
22 Side Burner Hose 2 41500228 55-2
Right Side Panel (Carbon Grey
Metallic)
1 50600051CB
23 Pulse Control Wire 1 50600226 56 Battery Module 1 41500223
24 Safety Switch & Rotisserie Valve 1 50600213 57 Battery Box 1 50600050
25 Gas Valve, Main Burner 5 50600211 58 Door Hinge 4 30800236
26 Gas Valve, Searing Burner 1 50600212 59 Match Holder 1 40800128
27 Manifold, Side Burner 2 41500042 60 Match Holder Bracket 1 30800255C
28 Manifold, Rotisserie Burner 1 50600030 61 Match Holder Chain 1 50600231
29 Manifold, Main Burner 1 50600024 62 Side Shelf Badge 1 50600201
30 Gas Hose 1 50600232C 63 Door Handle 2 50600069C
31 Gas Hose A 1 50600234 64-1 Right Door (SS) 1 50600066C
32 Regulator Retention Bracket 1 30800054 64-2
Right Door (Carbon Grey
Metallic)
1 50600066CB
33 Connector B 1 30800218 65 Right Door Handle Seats 2 30800250C
34 Regulator hose hanger clip 1 30800226 66 Left Door Handle Seats 2 30800249C




146.48591710 • 17
PART
S
LI
S
T
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from:
Those on
y
our
p
articular
g
rill model. However
,
the method of assembl
y
remains the same.:
