Operating Guide
7
B6VMAX SERIES AIR HANdLER
ITEM dESCRIPTIoN
B6VMAX24K-A
B6VMAXX24K-B
B6VMAXX30K-A
B6VMAXX30K-B
B6VMAXX36K-B
B6VMAXX42K-B
B6VMAXX48K-C
B6VMAXX60K-C
921164 921165 921166 921167 921168 921169 921171 921172
1
PLATE, CLOSE-OFF
(NOT SHOWN)
226420R 226420R 226420R 226420R 226420R 226420R 226420R 226420R
2
BLOWER HOUSING
297210R 297217R 297210R 297217R 297217R 297217R 297219R 297219R
3
PANEL, TOP
921877 921878 921877 921878 921878 921878 921879 921879
4
DOOR, FILTER
921874 921875 921874 921875 921875 921875 921876 921876
5
PLATE, TUBE CLOSE-OFF (NOT SHOWN)
921880 921880 921880 921880 921880 921880 921880 921880
6
HARNESS, FSHE / VSHE, UPPER
(NOT SHOWN)
2C0251R 2C0251R 2C0251R 2C0251R 2C0251R 2C0251R 2C0251R 2C0251R
7
HARNESS, FSHE, LOWER, (NOT SHOWN)
2C0253R 2C0253R 2C0253R 2C0253R 2C0253R 2C0253R 2C0253R 2C0253R
8
MOTOR, BLOWER
622500R 622500R 622500R 622500R 622500R 622500R 622501R 622501R
9
TRANSFORMER
621709R 621709R 621709R 621709R 621709R 621709R 621709R 621709R
10
CAPACITOR
— — — — — — — —
11
BOARD, CONTROL
624736R 624736R 624736R 624736R 624736R 624736R 624736R 624736R
12
BOARD, MOTOR CONTROL
624757R 624757R 624757R 624757R 624757R 624757R 624757R 624757R
13
DUAL GROUNDING LUG (NOT SHOWN)
632235R 632235R 632235R 632235R 632235R 632235R 632235R 632235R
14
PLUG, DRAIN PAN (NOT SHOWN)
663351R 663351R 663351R 663351R 663351R 663351R 663351R 663351R
15
DIST, ASSY (NOT SHOWN)
664256R 664219R 664257R 664219R 664219R 664219R 663586R 663586R
16
PLUG, CIRCULAR, PLASTIC, 1-3/4
(NOT SHOWN)
663710R 663710R 663710R 663710R 663710R 663710R 663710R 663710R
17
WHEEL, BLOWER
667251R 667258R 667251R 667258R 667258R 667258R 667280R 667280R
18
ROD, COIL SUPPORT (NOT SHOWN)
669100R 669100R 669100R 669100R 669100R 669100R 669100R 669100R
19
VALVE, TXV (NOT SHOWN)
669564R 669564R 669565R 669565R 669566R 669567R 669568R 669578R
20
DRAINPAN, VERTICAL
669919R 669920R 669919R 669920R 669920R 669920R 669921R 669921R
21
DRAINPAN, HORIZONTAL
669855R 669856R 669855R 669855R 669856R 669856R 669857R 669857R
22
PAINT, SPRAY, GRAY (NOT SHOWN)
903598 903598 903598 903598 903598 903598 903598 903598
23
BELLY-BAND
913871 903489 913871 903489 903489 903489 903489 903489
24
BLOWER, ASSEMBLY
921851 921855 921851 921855 921855 921855 921929 921929
25
ELECTRICAL ASSEMBLY (NOT SHOWN) M0063803R M0063803R M0063803R M0063803R M0063803R M0063803R M0063803R M0063803R
26
DOORS
921867 921869 921867 921868 921869 921869 921870 921870
27
SET OF WIRES, (NOT SHOWN) M0064403R M0064403R M0064403R M0064403R M0064403R M0064403R M0064403R M0064403R
28
FUSE, 3 AMP (NOT SHOWN)
632261R 632261R 632261R 632261R 632261R 632261R 632261R 632261R
29
COIL, REPLACEMENT (TUBE & FIN)
921951 921953 921951 921952 921953 921953 921955 921955
TUBE KIT (FOR REPLACEMENT COIL)
921287 921289 921287 921288 921289 921289 921291 921291
TXV KIT (FOR REPLACEMENT COIL)
920668A 920668A 920669A 920669A 920670A 920671A 920672A 920673A
30
FILTER DOOR FASTENERS
UNITS PRODUCED BEFORE 2/28/2014
(NOT SHOWN)
921402 921402 921402 921402 921402 921402 921402 921402
FILTER DOOR FASTENERS
UNITS PRODUCED ON OR AFTER 3/1/2014
(NOT SHOWN)
922458 922458 922458 922458 922458 922458 922458 922458
Please specify the correct Model No., Serial No., and Part No.(s) when ordering parts from the nearest authorized dealer or service center.
