Operating Guide
6
B6EMMX SERIES AIR HANdLER
ITEM dESCRIPTIoN
B6EMMX24K-A
B6EMMX24K-B
B6EMMX30K-A
B6EMMX30K-B
B6EMMX36K-B
B6EMMX42K-B
B6EMMX48K-C
B6EMMX60K-C
921155 921156 921157 921158 921159 921160 921162 921163
1
PLATE, CLOSE-OFF
(NOT SHOWN)
226420R 226420R 226420R 226420R 226420R 226420R 226420R 226420R
2
BLOWER HOUSING
297210R 297217R 297210R 297217R 297217R 297217R 297219R 297219R
3
PANEL, TOP
921877 921878 921877 921878 921878 921878 921879 921879
4
DOOR, FILTER
921874 921875 921874 921875 921875 921875 921876 921876
5
PLATE, TUBE CLOSE-OFF (NOT SHOWN)
921880 921880 921880 921880 921880 921880 921880 921880
6
HARNESS, FSHE / VSHE, UPPER
(NOT SHOWN)
2C0251R 2C0251R 2C0251R 2C0251R 2C0251R 2C0251R 2C0251R 2C0251R
7
HARNESS, FSHE, LOWER, (NOT SHOWN)
2C0252R 2C0252R 2C0252R 2C0252R 2C0252R 2C0252R 2C0252R 2C0252R
8
MOTOR, BLOWER
622500R 622500R 622500R 622500R 622500R 622500R 622501R 622501R
9
TRANSFORMER
621709R 621709R 621709R 621709R 621709R 621709R 621709R 621709R
10
CAPACITOR
— — — — — — — —
11
BOARD, CONTROL
624736R 624736R 624736R 624736R 624736R 624736R 624736R 624736R
12
BOARD, MOTOR CONTROL
624756R 624756R 624756R 624756R 624756R 624756R 624756R 624756R
13
DUAL GROUNDING LUG (NOT SHOWN)
632235R 632235R 632235R 632235R 632235R 632235R 632235R 632235R
14
PLUG, DRAIN PAN (NOT SHOWN)
663351R 663351R 663351R 663351R 663351R 663351R 663351R 663351R
15
DIST, ASSY (NOT SHOWN)
664588R 664588R 664588R 664588R 664588R 664588R 664588R 664588R
16
PLUG, CIRCULAR, PLASTIC, 1-3/4
(NOT SHOWN)
663710R 663710R 663710R 663710R 663710R 663710R 663710R 663710R
17
WHEEL, BLOWER
667251R 667258R 667251R 667258R 667258R 667258R 667280R 667280R
18
ROD, COIL SUPPORT (NOT SHOWN)
669100R 669100R 669100R 669100R 669100R 669100R 669100R 669100R
19
VALVE, TXV (NOT SHOWN)
669564R 669564R 669565R 669565R 669566R 669567R 669568 669578R
20
DRAINPAN, VERTICAL
669919R 669920R 669919R 669920R 669920R 669920R 669921R 669921R
21
DRAINPAN, HORIZONTAL
669855R 669855 669855R 669855R 669856R 669856R 669857R 669857R
22
PAINT, SPRAY, GRAY (NOT SHOWN)
903598 903598 903598 903598 903598 903598 903598 903598
23
BELLY-BAND
913871 903489 913871 903489 903489 903489 903489 903489
24
BLOWER, ASSEMBLY
921850 921865 921850 921865 921865 921865 921862 921862
25
ELECTRICAL ASSEMBLY (NOT SHOWN) M0063802R M0063802R M0063802R M0063802R M0063802R M0063802R M0063802R M0063802R
26
DOORS
921867 921868 921867 921868 921869 921869 921870 921870
27
SET OF WIRES, (NOT SHOWN)
921883 921883 921883 921883 921883 921883 921883 921883
28
FUSE, 3 AMP (NOT SHOWN)
632261R 632261R 632261R 632261R 632261R 632261R 632261R 632261R
29
MICROCHANNEL COIL
921482 921483 921482 921483 921484 921484 921486 921486
TUBE KIT (FOR REPLACEMENT COIL)
921732 921733 921732 921733 921734 921734 921736 921736
TXV KIT (FOR REPLACEMENT COIL)
920668A 920668A 920669A 920669A 920670A 920671A 920672A 920673A
30
FILTER DOOR FASTENERS
UNITS PRODUCED BEFORE 2/28/2014
(NOT SHOWN)
921402 921402 921402 921402 921402 921402 921402 921402
FILTER DOOR FASTENERS
UNITS PRODUCED ON OR AFTER 3/1/2014
(NOT SHOWN)
922458 922458 922458 922458 922458 922458 922458 922458
Please specify the correct Model No., Serial No., and Part No.(s) when ordering parts from the nearest authorized dealer or service center.
