Operating Guide

2
B6BMM0 AIR HANdLER
ITEM dESCRIPTIoN
B6BMM024K-A B6BMM024K-B B6BMM030K-A B6BMM030K-B B6BMM036K-B B6BMM042K-B B6BMM048K-B B6BMM048K-C B6BMM060K-C
921145 921146 921147 921148 921150 921151 921152 921153 921154
1
PLATE, CLOSE-OFF
(NOT SHOWN)
226420R 226420R 226420R 226420R 226420R 226420R 226420R 226420R 226420R
2
BLOWER HOUSING
297210R 297212R 297210R 297212R 297212R 297212R 297212R 297214R 297219R
3
PANEL, TOP
921877 921878 921877 921878 921878 921878 921878 921879 921879
4
DOOR, FILTER
921874 921875 921874 921875 921875 921875 921875 921876 921876
5
PLATE, TUBE CLOSE-OFF
(NOT SHOWN)
921880 921880 921880 921880 921880 921880 921880 921880 921880
6
HARNESS, FSHE / VSHE, UPPER
(NOT SHOWN)
— — — — — — — — 2C0251R
7
HARNESS, FSHE, LOWER,
(NOT SHOWN)
— — — — — — — — 2C0252R
8
MOTOR, BLOWER
622257R 622257R 622264R 622258R 622258R 622260R 622260R 622261R 622501R
9
TRANSFORMER
621709R 621709R 621709R 621709R 621709R 621709R 621709R 621709R 621709R
10
CAPACITOR
622535R 622535R 622550R 622545R 622545R 622545R 622545R 622549R —
11
BOARD, CONTROL
624735R 624735R 624735R 624735R 624735R 624735R 624735R 624735R 624736R
12
BOARD, MOTOR CONTROL
— — — — — — — — 624756R
13
DUAL GROUNDING LUG
(NOT SHOWN)
632235R 632235R 632235R 632235R 632235R 632235R 632235R 632235R 632235R
14
PLUG, DRAIN PAN (NOT SHOWN)
663351R 663351R 663351R 663351R 663351R 663351R 663351R 663351R 663351R
15
DIST, ASSY (NOT SHOWN)
664588R 664588R 664588R 664588R 664588R 664588R 664588R 664588R 664588R
16
PLUG, CIRCULAR, PLASTIC, 1-3/4
(NOT SHOWN)
663710R 663710R 663710R 663710R 663710R 663710R 663710R 663710R —
17
WHEEL, BLOWER
667251R 667037R 667251R 667037R 667037R 667037R 667037R 667207R 667280R
18
ROD, COIL SUPPORT (NOT SHOWN)
669100R 669100R 669100R 669100R 669100R 669100R 669100R 669100R 669100R
19
VALVE, TXV (NOT SHOWN)
— — — — — — — — —
20
DRAINPAN, VERTICAL
669919R 669920R 669919R 669920R 669920R 669920R 669920R 669921R 669921R
21
DRAINPAN, HORIZONTAL
669855R 669855R 669855R 669855R 669855R 669856R 669856R 669857R 669857R
22
PAINT, SPRAY, GRAY (NOT SHOWN)
903598 903598 903598 903598 903598 903598 903598 903598 903598
23
BELLY-BAND
913871 913871 913871 913871 913871 913871 913871 913871 903489
24
BLOWER, ASSEMBLY
921852 921858 921849 921854 921854 921866 921866 921847 921862
25
ELECTRICAL ASSEMBLY
(NOT SHOWN)
M0063801R M0063801R M0063801R M0063801R M0063801R M0063801R M0063801R M0063801R M0063802R
26
DOORS
921867 921868 921867 921868 921868 921869 921869 921870 921870
27
SET OF WIRES (NOT SHOWN)
921881 921881 921881 921881 921881 921881 921881 921881 921883
28
FUSE, 3 AMP (NOT SHOWN)
632261R 632261R 632261R 632261R 632261R 632261R 632261R 632261R 632261R
29
MICROCHANNEL COIL
921482 921483 921482 921483 921483 921484 921484 921486 921486
30
FILTER DOOR FASTENERS - UNITS
PRODUCED BEFORE 2/28/2014
(NOT SHOWN)
921402 921402 921402 921402 921402 921402 921402 921402 921402
FILTER DOOR FASTENERS - UNITS
PRODUCED ON OR AFTER 3/1/2014
(NOT SHOWN)
922458 922458 922458 922458 922458 922458 922458 922458 922458
Please specify the correct Model No., Serial No., and Part No.(s) when ordering parts from the nearest authorized dealer or service center.
