Operating Guide

5
B6EMMN SERIES AIR HANdLER
ITEM dESCRIPTIoN
B6EMMNX36K-B B6EMMNX60K-C
922467 922470
1
PLATE, CLOSE-OFF
(NOT SHOWN)
226420R 226420R
2
BLOWER HOUSING
297217R 297219R
3
PANEL, TOP
921878 921879
4
DOOR, FILTER
921875 921876
5
PLATE, TUBE CLOSE-OFF (NOT SHOWN)
921880 921880
6
HARNESS, FSHE / VSHE, UPPER
(NOT SHOWN)
2C0251R 2C0251R
7
HARNESS, FSHE, LOWER, (NOT SHOWN)
2C0252R 2C0252R
8
MOTOR, BLOWER
622500R 622501R
9
TRANSFORMER
622036R 622036R
10
CAPACITOR
— —
11
BOARD, CONTROL
624736R 624736R
12
BOARD, MOTOR CONTROL
624756R 624756R
13
DUAL GROUNDING LUG (NOT SHOWN)
632235R 632235R
14
PLUG, DRAIN PAN (NOT SHOWN)
663351R 663351R
15
DIST, ASSY (NOT SHOWN)
— —
16
PLUG, CIRCULAR, PLASTIC, 1-3/4
(NOT SHOWN)
663710R 663710R
17
WHEEL, BLOWER
667258R 667280R
18
ROD, COIL SUPPORT (NOT SHOWN)
669100R 669100R
19
VALVE, TXV (NOT SHOWN)
— —
20
DRAINPAN, VERTICAL
669920R 669921R
21
DRAINPAN, HORIZONTAL
669856R 669857R
22
PAINT, SPRAY, GRAY (NOT SHOWN)
903598 903598
23
BELLY-BAND
903489 903489
24
BLOWER, ASSEMBLY
921865 921862
25
ELECTRICAL ASSEMBLY (NOT SHOWN) M0063802R M0063802R
26
DOORS
921869 921870
27
SET OF WIRES, (NOT SHOWN)
921883 921883
28
FUSE, 3 AMP (NOT SHOWN)
632261R 632261R
29
MICROCHANNEL COIL
921484 921486
TUBE KIT (FOR REPLACEMENT COIL)
921734 921736
30
FILTER DOOR FASTENERS
UNITS PRODUCED BEFORE 2/28/2014
(NOT SHOWN)
921402 921402
FILTER DOOR FASTENERS
UNITS PRODUCED ON OR AFTER 3/1/2014
(NOT SHOWN)
922458 922458
Please specify the correct Model No., Serial No., and Part No.(s) when ordering parts from the nearest authorized dealer or service center.
