B6BMMX SERIES AIR HANdLER
ITEM dESCRIPTIoN
B6BMMX24K-A B6BMMX24K-B B6BMMX30K-A B6BMMX30K-B B6BMMX36K-B B6BMMX42K-B B6BMMX48K-C B6BMMX60K-C
922082 922083 922084 922085 922086 922087 922088 922089
1
PLATE, CLOSE OFF (NOT SHOWN)
226420R 226420R 226420R 226420R 226420R 226420R 226420R 226420R
2
BLOWER HOUSING
297210R 297212R 297210R 297212R 297212R 297212R 297214R 297214R
3
PANEL, TOP
921877 921878 921877 921878 921878 921878 921879 921879
4
DOOR, FILTER
921874 921875 921874 921875 921875 921875 921876 921876
5
PLATE, TUBE CLOSE OFF
921880 921880 921880 921880 921880 921880 921880 921880
6
HARNESS, FSHE/VSHE, UPPER
(NOT SHOWN)
- - - - - - - -
7
HARNESS, FSHE, LOWER
(NOT SHOWN)
- - - - - - - -
8
MOTOR, BLOWER
622257R 622257R 622264R 622258R 622258R 622260R 622261R 622501R
9
TRANSFORMER
621709R 621709R 621709R 621709R 621709R 621709R 621709R 621709R
10
CAPACITOR
622535R 622535R 622550R 622545R 622545R 622545R 622549R -
11
BOARD, CONTROL
624735R 624735R 624735R 624735R 624735R 624735R 624735R 624736R
12
BOARD, MOTOR CONTROL
- - - - - - - 624765R
13
DUAL GROUNDING LUG (NOT
SHOWN)
632235R 632235R 632235R 632235R 632235R 632235R 632235R 632235R
14
PLUG, DRAIN PAN
663351R 663351R 663351R 663351R 663351R 663351R 663351R 663351R
15
DIST, ASSY
664588R 664588R 664588R 664588R 664588R 664588R 664588R 664588R
16
PLUG, CIRCULAR PLASTIC
663710R 663710R 663710R 663710R 663710R 663710R 663710R 663710R
17
WHEEL, BLOWER
667251R 667037R 667251R 667037R 667037R 667037R 667207R 667280R
18
ROD, COIL SUPPORT (NOT SHOWN)
669100R 669100R 669100R 669100R 669100R 669100R 669100R 669100R
19
VALVE, TXV
669564R 669564R 669565R 669565R 669566R 669567R 669568R 669578R
20
DRAIN PAN, VERTICAL
669919R 669920R 669919R 669920R 669920R 669920R 669921R 669921R
21
DRAIN PAN, HORIZONTAL
669855R 669855R 669855R 669855R 669855R 669856R 669857R 669857R
22
PAINT
903958 903958 903958 903958 903958 903958 903958 903958
23
BELLY BAND
913871 913871 913871 913871 913871 913871 913871 903489
24
BLOWER ASSEMBLY
921852 921858 921849 921854 921854 921866 921847 921862
25
ELECTRICAL ASSEMBLY M0063801R M0063801R M0063801R M0063801R M0063801R M0063801R M0063801R M0063802R
26
DOORS
921867 921868 921867 921868 921868 921869 921870 921870
27
SET OF WIRES
921881 921881 921881 921881 921881 921881 921881 921883
28
FUSE, 3 AMP
632261R 632261R 632261R 632261R 632261R 632261R 632261R 632261R
29
MICROCHANNEL COIL
921842 921843 921842 921843 921843 921484 921486 921486
TUBE KIT (FOR REPLACEMENT COIL)
921732 921733 921732 921733 921733 921734 921736 921739
TXV KIT (FOR REPLACEMENT COIL)
920668A 920668A 920669A 920669A 920669A 920671A 920672A 920673A
30
FILTER DOOR FASTNERS
(BEFORE 2/28/14)
921402 921402 921402 921402 921402 921402 921402 921402
FILTER DOOR FASTNER
(AFTER 3/1/14)
922458 922458 922458 922458 922458 922458 922458 922458
Please specify the correct Model No., Serial No., and Part No.(s) when ordering parts from the nearest authorized dealer or service center.
