SharpEye Az i muth In ter face PCB (DTX-A151) - Re moval
28 To remove the SharpEye
TM
Azimuth Interface PCB, proceed as follows:
(1) Remove the connectors from the SharpEye
TM
Azimuth Interface PCB.
(2) Remove and retain the two screws securing the SharpEye
TM
Azimuth Interface
PCB and remove the PCB.
SharpEye Az i muth In ter face PCB (DTX-A151) - Re place ment
29 To replace the SharpEye
TM
Azimuth Interface PCB reverse the above procedure.
KH1264
Chap ter 6
Page 6.16 Is sue 2
