10 To access the units inside the upmast transceiver, remove the side cover of the
transceiver. This allows access to the transceiver and the power supply and allows the
LEDs on the PSU Sense PCB and CAN Adapter PCB to be seen.
WARNING
IT IS DANGEROUS TO RUN THE TRANSCEIVER WHEN UPMAST AS THE
ANTENNA IS ROTATING AND RF IS RADIATED. UNDER NO
CIRCUMSTANCES SHOULD THE MAINTAINER BE UPMAST WHEN RF IS
RADIATED AND/OR THE ANTENNA IS ROTATING. THEREFORE ALL
CHECKS MUST BE MADE WITH THE TRANSCEIVER IN STANDBY MODE,
THIS WILL LIMIT THE CHECKS THAT CAN BE MADE WHEN THE
TRANSCEIVER IS SET TO RUN.
IN DI CA TORS (Fig ure 1)
11 The indicators provided on the CAN Adapter PCB are as follows:
D4 MUTE. Unlit (not used) (Lit when mute active)
D5 RUN. Unlit (not used) (Lit when Run is active)
D11 +15 V. Lit when +15 V supply present
D12 -15 V. Lit when -15 V supply present
D13 RUNNING. Flashes when processor running
D14 LED 1. Lit when heartbeat received
D15 LED 2. Unlit (not used)
D16 +24 V. Lit when +24 V supply present
D38 +5 V. Lit when +5 V supply present
