WARNING
IF OPERATION FROM THE INVERTER FRONT PANEL IS SELECTED, THE
MAN ALOFT SAFETY KEYSWITCH IS OVERRIDDEN. NEVER SELECT
OPERATION FROM THE INVERTER FRONT PANEL FOR NORMAL
OPERATIONAL USE.
(11) To select operation from the inverter front panel set function CN0d to 1
(Start/Stop local control) and FN0d to 1 (Frequency set by Ý ß). Set both
functions to 0 to return to remote control (normal operation).
8 The parameters are set as follows (set for 50 Hz operation in the factory):
FUNCTION DESCRIPTION SET OPERATION
AUH HISTORY FUNCTION
AUF WIZARD FUNCTION
CN0d COMMAND MODE 0 TERMINAL BLOCK
FN0d FREQUENCY SETTING MODE 0 TERMINAL BLOCK
FNSL FM/OUT TERMINAL FUNCTION
SELECTION
0 DEFAULT NOT USED
FN METER ADJUSTMENT 0
typ STANDARD SETTING MODE 1--0
2--0
3--0
50 Hz, sets FH, UL, uL & F170 to 50
60 Hz, sets FH, UL, uL & F170 to 60
FACTORY DEFAULT
FR FORWARD/REVERSE 0 FORWARD
ACC ACCELERATION TIME 2 SECONDS
dEC DECELERATION TIME 10 SECONDS
FH MAXIMUM FREQUENCY 50/60 50 Hz or 60 Hz (set by typ)
UL UPPER LIMIT FREQUENCY 50/60 50 Hz or 60 Hz (set by typ)
LL LOWER LIMIT FREQUENCY 0 0 Hz
uL BASE FREQUENCY (MOTOR) 50/60 50 Hz or 60 Hz (set by typ)
Pt V/F CONTROL MODE SELECTION 0 VOLTAGE/FREQUENCY CONSTANT
ub TORQUE BOOST 5 5% BOOST
tHr MOTOR THERMAL PROTECTION LEVEL 80 80% (EQUIVALENT 1.5 kW MOTOR)
0LN ELECTRONIC THERMAL PROTECTION
LEVEL
0 OVERLOAD PROTECTION OFF
OVERLOAD STALL ON
Sr-1 PRESET SPEED FREQUENCY 1 0 0 Hz
Sr-2 PRESET SPEED FREQUENCY 2 25 25 Hz
Sr-3 PRESET SPEED FREQUENCY 3 50 50 Hz
Sr-4 PRESET SPEED FREQUENCY 4 0 0 Hz
Sr-5 PRESET SPEED FREQUENCY 5 0 0 Hz
Sr-6 PRESET SPEED FREQUENCY 6 0 0 Hz
Sr-7 PRESET SPEED FREQUENCY 7 0 0 Hz
F— EXTENDED PARAMETER ENT
F109 ANALOG/LOGIC INPUT FUNCTION
SELECT
2 CONTACT INPUT
F127 SINK/SOURCE INPUT SELECTION 100 SOURCE
F170 BASE FREQUENCY 2 50/60 50 Hz or 60 Hz (set by typ)
F300 PWM CARRIER FREQUENCY 2 4 kHz
F301 AUTO RESTART 0 DISABLED
F302 REPETITIVE POWER RIDE-THROUGH 0 DISABLED
F303 RETRY SELECTION
F417 MOTOR SPEED 2820
3384
For 50 Hz
For 60 Hz
Gr..U SEARCH FOR CHANGED SETTINGS
THIS MENU ONLY SHOWS PARAMETERS
THAT ARE NOT SET TO DEFAULT VALUE.
GIVES FAST TRACK THROUGH MENUS.
KH1264
Chap ter 5
Is sue 2 Page 5.5
