CHAPTER 5
COMMISSIONING
IN TRO DUC TION
1 Interswitched equipments, or equipments interfaced with other radar equipments, are
described in their respective Handbooks.
POWER SUP PLIES
2 Check that all cables have been installed and connected.
SET TING TO WORK
WARNING
WHEN WORKING ON THE UPMAST TRANSCEIVER ALWAYS ENSURE THE
ON/OFF SWITCH ON THE DRIVE CONTROL UNIT IS SET TO OFF AND THE
KEY IS WITHDRAWN. THE KEY SHOULD BE RETAINED BY THE
INSTALLER WHEN WORKING ALOFT. REMOVAL OF THE KEY PREVENTS
THE ANTENNA FROM ROTATING.
3 Carry out the following:
(1) Switch on the single phase mains at the Isolators for the Display and Transceiver.
(2) Set the Drive Control Unit switch to OFF. Ensure the switch IS NOT set to ON.
(3) Set the display power switch to ON.
4 At the display ensure that the Transceiver is entered as SharpEye
TM
in the installed
equipment parameters. The following parameters are set up from the display system,
refer to your system manual (KH2020, KH2026 and KH2061), as appropriate, for details of
accessing these menus:
(1) Operating Frequency. SharpEye
TM
contains 14 pre-set transmission frequencies
within the operating frequency band.
(2) Reverse Sweep Mode. To minimise in-band asynchronous interference from
other X-Band SharpEye
TM
radars in the same locality, the operator is able to
select a reverse sweep mode.
(3) Transmit Inhibit Sector. The SharpEye
TM
radar provides one blanking sector
that is configured via the Display. Within the blanking sector, the SharpEye
TM
radar does not transmit RF energy.
KH1264
Chap ter 5
Is sue 2 Page 5.3
