KH1264
Chap ter 4
Is sue 2 Page 4.9
CD-7629
ISSUE 1
ALL DIMENSIONS IN MILLIMETRES UNLESS OTHERWISE STATED
ALL DIMENSIONS NOMINAL
CENTRE OF GRAVITY DIMENSIONS ARE ESTIMATED
AT 0% RELATIVE HUMIDITY: -25°C to +70°C
AT 95% RELATIVE HUMIDITY: +40°C
OPERATING TEMPERATURE RANGE
ANTENNA WEIGHT
Tx & TURNING MECH
-kg
-kg
C of G
2509
534
192
C of G
3-CORE MOTOR POWER CABLE FED THROUGH
CABLE GLAND ON MOTOR TERMINAL BLOCK
14-CORE & 2-CORE CABLES FED THROUGH
CABLE GLANDS AT REAR OF CASE
CABLES FED THROUGH NOTCH
IN MOUNTING PLATE
FWD
NOTE: REFER TO FIGURE 4 FOR MOUNTING DETAILS
STANDARD COMPASS GRADE I
STEERING COMPASS GRADE II & III
GRADE IV
TBD
TBD
TBD
COMPASS SAFE DISTANCES:
DO NOT LIFT HERE
PTFE WINDOW FITTED AT THIS CONNECTION
85
Figure 1 - Transceiver (DTX-A3): Installation Dimensions
