User's Manual
Table Of Contents
- KH1264 ISSUE 1
- CHAPTER 1
- CHAPTER 2
- CHAPTER 3
- CONTENTS
- ILLUSTRATIONS
- Figure 1 - Transceiver (DTX-A3): Module Locations 34
- Figure 2 - Drive Control Unit (GTX-A24): Module Locations 35
- Figure 3 X-band Upmast Transceiver (DTX-A3): Functional Diagram Figure 3 38
- Figure 4 X-band Upmast Transceiver (DTX-A3): Interconnection Diagram Figure 4 39
- Figure 5 - Drive Control Unit (GTX-A24): Block Diagram 319
- CHAPTER 4
- CONTENTS
- TABLES
- ILLUSTRATIONS
- Figure 1 - Transceiver (DTX-A3): Installation Dimensions 49
- Figure 2 - Transceiver (DTX-A3): Mast Mounting 410
- Figure 3 - Transceiver (DTX-A3): Fitting Kit 411
- Figure 4 - Suggested Antenna Lifting Arrangement 412
- Figure 5 - Drive Control Unit (GTX-A24): Installation Dimensions 413
- Figure 6 - Mains Isolator: Installation Dimensions 414
- Figure 7 - Transceiver (DTX-A3): Cableform Routing 419
- Figure 8 - Drive Control Unit (GTX-A24): Cableform Routing 420
- Figure 9 - Cable Gland: Assembly 421
- Figure 10 - Transceiver (DTX-A3): External Connections 423
- CHAPTER 5
- CHAPTER 6
- CONTENTS
- INTRODUCTION 63
- PLANNED MAINTENANCE 63
- DIAGNOSTIC MAINTENANCE 64
- CORRECTIVE MAINTENANCE 611
- TRANSCEIVER (DTX-A3) 612
- Access 612
- Removal of Rotating Joint (45-750-0034-001) 612
- Replacement of Rotating Joint (45-750-0034-001) 613
- Removal of Gearbox and Motor (55-100-0273-001) 613
- Replacement of Gearbox and Motor (55-100-0273-001) 613
- Removal of Azimuth Encoder (GTX-A188) 613
- Replacement of Azimuth Encoder (GTX-A188) 613
- Transceiver (DTX-A115) - Removal 614
- Transceiver (DTX-A115) - Replacement 614
- Power Supply (45-690-0062-002) and PSU Sense PCB (DTX-A121) - Removal 615
- Power Supply (45-690-0062-002) and PSU Sense PCB (DTX-A121) - Replacement 615
- CAN Adapter PCB (NNR-A981) - Removal 615
- CAN Adapter PCB (NNR-A981) - Replacement 615
- SharpEye Azimuth Interface PCB (DTX-A151) - Removal 616
- SharpEye Azimuth Interface PCB (DTX-A151) - Replacement 616
- DRIVE CONTROL UNIT (GTX-A24) 618
- CHECKS AFTER UNIT REPLACEMENT 620
- TRANSCEIVER (DTX-A3) 612
- ILLUSTRATIONS
- CONTENTS
- CHAPTER 7
- INSTALLATION AND SERVICE REPORTS
IN STAL LA TION
UPMAST TRANS CEIVER (DTX-A3)
WARNING
ENSURE THAT ALL POWER SUPPLIES IN THE VICINITY OF THE
TRANSCEIVER ARE ISOLATED BEFORE ANY INSTALLATION TAKES
PLACE.
21 The SharpEye
TM
Upmast Transceiver is supplied in two parts:
(1) Transceiver with Gearbox.
(2) Antenna.
22 The SharpEye
TM
Upmast Transceiver is fitted with a Low Profile Antenna (LPA-A25).
23 The ship’s mounting structure must be capable of withstanding the high starting and
stopping torque generated by the motor fitted in the upmast transceiver.
24 When mounting the upmast transceiver observe the following:
(1) Use the fitting pack supplied with the equipment (refer to Figure 3). The fitting
pack contains fixings that have been tested to withstand the stresses detailed in
paragraph 24.
(2) Recommended tensile strengths and torque loadings for the fixings are stated on
the installation diagram.
(3) For upmast transceivers mounted in excess of 1.8 m above the deck, it is
recommended that a service platform and guard rail are fitted.
(4) Use a suitable jointing compound or sealant to prevent corrosion between the
platform and upmast transceivers/turning mechanism.
CAUTION
The Antenna Window Must NOT Be Painted.
(5) Any chipped or damaged surfaces must be painted with polyurethane paint.
25 With reference to Figures 1, 2 and 3, install the upmast transceiver and antenna following
the procedures below.
26 It is recommended that the antenna is fitted after installing the transceiver/turning
mechanism to avoid damage to the antenna. Only fit the antenna prior to installing the
transceiver/turning mechanism if absolutely necessary, in which case care must be taken to
avoid damage to the antenna when lifting the combined assembly.
KH1264
Chap ter 4
Page 4.6 Is sue 2
