EQUIP MENT LO CA TION
UPMAST TRANS CEIVER (DTX-A3)
13 The Upmast Transceiver should be installed in such a position where Blind Arcs, caused
by obstructions, i.e. masts, funnels etc, are eliminated or minimised. Funnels, crosstrees
and other large obstructions can also reflect energy and give rise to spurious echo returns
especially in close proximity to land. Positioning the antenna close to funnels and exhaust gases
can adversely affect antenna performance.
14 The Upmast Transceiver is to be mounted on a rigid platform, which is positioned so that
the rotating antenna is clear of other structures.
15 The primary consideration must be the strength of the support for the Upmast
Transceiver/Antenna assembly. Details of the requirement are described in the following
sub-paragraphs:
(1) The antenna must be mounted more than 914 mm (3 ft) above any flat surface
greater than the diameter swept by the antenna. It must not be positioned in close
proximity of any magnetic compass or D/F aerial etc.
(2) Masts, sampsons, posts and rigging of more than 0.6 m (2 ft) diameter can cause
blind sectors. Increasing the distance between the antenna unit and these objects
will reduce the blind sectors that inhibit a good radar picture.
16 The Upmast Transceiver must not be mounted where the temperature exceeds 70
o
C.
17 The Upmast Transceiver must be kept clear of ship’s flexible communication aerials to
avoid damage to both.
DRIVE CON TROL UNIT (GTX-A24)
18 The Drive Control Unit is designed for bulkhead mounting and must be sited as near the
Transceiver as possible, the maximum cable run between the Drive Control Unit and
Transceiver is 65 m.
19 The Drive Control Unit must be sited to allow removal of the front cover, access to the
cable glands and removal of the key from the keyswitch, which is essential when working
aloft.
OP TIONAL MAINS ISO LA TOR (80-261-600)
20 The Mains Isolator must be sited adjacent to the display or in the area of the operators
control room and connected in parallel with the main display.
KH1264
Chap ter 4
Is sue 2 Page 4.5
