SAFETY NOTES
Observe the Health and Safety Notices at the front of this manual. In
particular, the procedures given in the Code of Safe Working Practices
CP225 MUST be followed. Failure to follow these procedures and to
complete and return the Warranty card will invalidate the warranty on the
equipment.
7 Safety personnel must ensure that persons do not encroach on the area of work.
8 Electrical supplies are to be isolated to any part of the platform when mounting an upmast
transceiver/turning mechanism. A suitable safety platform or harness should be used to
avoid personal injury when working aloft.
9 Electrical supplies in the vicinity of the transceiver are to be isolated during installation.
10 A working platform is to be provided for installing or servicing the assembly. This should
be positioned approximately a metre below the base of the Upmast Transceiver housing
with a guard rail surrounding it.
11 The Upmast Transceiver must be hoisted to the fixing position using a secured block and
tackle or rope strops.
12 The Upmast Transceiver MUST NOT be lifted by the array, but the complete unit
secured and hoisted evenly. The antenna must be installed after the upmast transceiver
has been installed.
WARNING
WHEN WORKING ON THE UPMAST TRANSCEIVER ALWAYS ENSURE THE
ON/OFF SWITCH ON THE DRIVE CONTROL UNIT IS SET TO OFF AND THE
KEY IS WITHDRAWN. THE KEY SHOULD BE RETAINED BY THE
INSTALLER WHEN WORKING ALOFT. REMOVAL OF THE KEY PREVENTS
THE ANTENNA FROM ROTATING.
THE INVERTER MUST BE SET TO REMOTE OPERATION DURING
COMMISSIONING, OTHERWISE THE KEYSWITCH FUNCTION WILL BE
OVERRIDDEN.
THE UPMAST TRANSCEIVER USES A 110 V/220 V MAINS SUPPLY FOR THE
TRANSCEIVER ELECTRONICS. THIS SUPPLY IS NOT ISOLATED BY THE
KEYSWITCH IN THE DRIVE CONTROL UNIT, AND MUST BE ISOLATED AT
THE MAINS ISOLATOR.
